Outdoor 8 Camera Wireless Cctv Systems , House Security Camera Kit 1080P

Outdoor WiFi CCTV Camera Kit Built in 15.6 Inch 1080P 8Channel Wireless NVR

Quick Detail

WIFI NVR Kit SAV-W15LN08K20 is adopting the automatic password generation mechanism to ensure that the monitored video will not be eavesdropped if the default password is used. It is very simple to operate and suitable for all kinds of scenes. The Wifi Kits are loved by a majority of users.

Features

High Resolution LCD Screen Resolution up to 1920X1080.
True 8 X 1080P HD IP cameras are exceptionally smooth, night vision is up to 100ft in the dark with IR-CUT double filter lens.
Wireless 8 channels NVR plug and play system. Easy to set up and DIY Installation. only need to plug them in power to start working with AUTO-PAIR technology.
Remote Viewing Anywhere Anytime. You can view the cameras remotely on your smartphone, iPad or PC anywhere anytime once the system is set up.
Motion Alerts: Push Notifications Instantly When Motion are Detected.

Specifications

Model	SAV-W15LN08K20
Wireless NVR Specification
Operating System	Embedded Linux OS
LCD Screen	15.6 inch 1920 * 1080 LCD Screen
Network Video	8CH
Network video input broadbank	20 Mbps
AUdio Bitrate	64 Kbps
HDMI input	1 ch,resolution:1024x768,1366x768, 1440x900,1920x1080p
VGA output	1ch,resolution:1024x768,1366x768, 1440x900,1920x1080p
Video Resolution	D1/720P/960P/1080P
synch-playback	8CH
Video/Capture mode	Maual, Time, Motion, Alarm
Playback mode	Real time, Routine, Event
Backup	USB backup
Alarm Input	4CH (optional)
Alarm Output	1ch (optional)
Type	1*SATA interface
Max Capacity	4 TB at most for each
Network Interface	1 adaptable RJ45 10M/100M, 1 WIFI interface
USB Interface	2 USB 2.0
Protocol	UPnP (play&plug)/SMTP (email survice) / PPPoE (dial-up) DHCP (Automatically obtain an IP address), etc…
Power Supply	DC12V3A
Power Consumption (W)	≤5W(Without HDD)
Operate Temperature (°C)	-10℃~+55℃
Working Humidity (%) RH	10%~90%
Size	257mm(W)×210mm(V)×45mm(H)
Weight(excluding HDD)	≤1Kg
IP Camera Specification
Sensor	1/3" Progressive Scan Sensor
Signal System	PAL/NTSC
Resolution	1080P 16 : 9 High Defination
Minimum illumination	Color: 0.1 Lux; B/W: 0.01 Lux
Shutter	1/25s to 1/25,000s
Lens	3.6mm
OSD	Date Time & Title
White Balance	Auto
Day&Night	Auto / Color / BW
3D-DNR	Auto
Mirror/Flip	On / Off
Frame Specification	Three Streaming at the Same Time: H.264 128x720@30fps or below H.264 640x480@30fps or below
S/N	> 39.1 Db
Interface	RJ45 / WIFI 802.11b/g/n
Anti-thunder Level	Standard IEC61000-4-5
Working Temperature	-20℃ to +60℃ / 20% to 90% RH
Power Input	DC12V-1A
Power consumption	≤6W
Size	205(L)×70(W)×55 (H)mm
Weight	500g
Waterproof	IP66

Packing List

1 PCS * 8CH WIFI 15inch LCD NVR
8 PCS * WIFI IP camera
8 PCS * Adaptor for 4pcs IP camera
1 PCS * Adaptor for WIFI NVR
1 PCS * USB Mouse
1 PCS * User Manual

Application

SAV-W15LN08K20 suitable for a wide range of video surveillance applications, including government and industrial buildings, retail environments, hotel, home and schools.
