| WiFi NVR recorder |
| Network video input | 4 channels 1 megapixel |
| Operating system | Embedded Linux |
| Main processor | HI3520D |
| Operating interface | 24-bit true color graphical menu interface with mouse operation |
| Image decoding | Low/ Medium/ High |
| Video mode | Alarm/ Manual/ Motion detection/ timing |
| Local playback | 1/4 |
| Backup method | USB/ Mobile hard disk |
| Audio input | 1 |
| Network Interface | 1RJ45 10M/100M adaptive Ethernet port 5DB copper antenna |
| Hard disk interface | 1 SATA interface (maximum support for 6T hard drives) |
| Working environment | 0℃~50℃;Humidity less than 90% (no condensation) |
| Sensor | 1/4” CMOS |
| Minimum illumination | Color:0.05Lux@ F1.2; B/W: 0.01Lux@ F1.2 |
| Night vision distance | 30m |
| Lens type | Fixed |
| White balance | Auto/ Manual |
| Digital noise reduction | 3D DNR |
| Video compression | H.264 |
| Compressed bit rate | 32 Kbps~6Mbps(960P)32Kbps~4Mbps(720P) |
| Support video format | 720P/960H/360P |
| Image setting | Adjustable brightness, contrast, saturation, |
| gain, shutter, white balance, etc. |
| AD sampling accuracy | 12 bit |
| P2P function | Mobile/ Computer/ PAD/ Web |
| General function | One-click recovery, dual stream, heartbeat, mirroring, |
| video masking, anonymous access, etc. |
| Power supply | DC12V/1A |
| Working environment | -10℃~50℃,30%~80%RH |
| Dimension | 260(L)*224(W)*48(H)mm |
| Wireless transmission distance | 400 meter (without wall) |
| system resource | Simultaneous multi-channel real-time recording, |
| real-time playback, multi-channel multi-person network operation,
USB backup |
| Screen display | 1/4 |
| Motion Detection | 396 (22*18) detection areas can be set per screen; |
| sensitivity can be set |
| Playback quality | 960P/720P/960H/360P |
| Video output | 1 HDMI,1 VGA |
| USB interface | 1*USB 2.0 |
| Power supply | DC12V/2A |
| Net weight | 1000g(Not include HDD) |
| WiFi camera |
| Resolution | 1 megapixel,1280(H)*720(V) |
| Electronic shutter | NTSC: 1/30---1/10000S; PAL: 1/25---1/10000S |
| focal length | 4mm/ 6mm optional |
| Day and night conversion | IRC/ Manual |
| Gain control | Auto/ Manual |
| Frame rate | 50HZ: 25fps; 60HZ: 30fps |
| Mirror | Support horizontal, vertical, diagonal, normal mode mirroring |
| Supporting agreement | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, RTP, RTSP, RTCP, |
| NTP, UPnP, SMTP, SNMP, IGMP, 802.1X |
| Intelligent alarm | Motion detection, occlusion alarm, video loss |
| Communication Interface | 1 RJ45 10M / 100M adaptive Ethernet port |
| Protection level | IP66 |
| Net weight | 500g |
