| Parameter/model | Parameter/model MY-57S-UB(wall)/MY-57S-UD(lifting) |
| PTZ Paramerers | Infrared distance | 60 meters |
| Horizontal range and speed | Horizontal 360° continuous rotation, speed 0.6°～ 200° |
| Vertical range and speed! | 0～90°,Support automatic rollover,speed 3.5°～30°/s |
| Speed of hand control | High, medium, low three adjustable. |
| Movement parameters | Videoparameters | The resolution of the | 2304X1296@30fps or 2592x1520@22fps |
| The sensor | 1/3” 4.0M Pixel OV4689 CMOS |
| Low illumination | color:0.05Lux@F1.6; Black and white:0.01Lux@F1.6; 0 Lux(The red
light is on) |
| Electronic shutter | 1/2～1/20,000 seconds,Support slow shutter |
| The lens parameters | The focal length | 4.7mm -47mm |
| Viewing Angle | 70.9°(The distal)/ 7.1°(The proximal) |
| aperture | F1.6—F2.5 |
| The exposure mode | Program(Customizable shutter range),The shutter mode |
| Function | The white balance | Automatic, indoor, outdoor, sodium lamp mode, manual. |
| Image image! | Horizontal/vertical/horizontal + vertical/close. |
| Digital noise reduction | Support DNR,3DNR |
| Gain control! | Automatic/manual |
| Wide dynamic | 73.7dB |
| Day and night conversion | | automatic ICR filter color black, fixed black and white.,Fixed
color, external control. |
| Privacy protection | Support 3D privacy area, open/close (the same screen can set up 4
privacy areas) |
| More stream | supports dual coding.,Three-yard flow,H.265 Main Profile / H.264
Main profile / M-JPEG |
| Network protocol | TCP/IP,HTTP,NTP,IGMP,DHCP,UDP,SMTP,RTP,RTSP,ARP,DDNS,DNS,HTTPS,802.1X,P2P |
| interface | The network interface | 10/100M Ethernet, RJ45 interface, |
| Power supply and control interface. | DC 12V/2A(Optional POE power supply standard IEEE 802.3at),RS485 |
| other | Power consumption | 20W(MAX) |
| Working temperature and humidity | -30℃～+60℃,≤90%RH(No condensation) |
| Protection grade | TVS3000V lightning protection, surge prevention, anti-rush wave;
Outdoor ball: IP66 |
| Packing size(mm) | 280*280*225 |
| The weight of the(Kg) | 4KG(With movement) |
